SWITCHES
Low Profile Brass Chrome Plated Vandal Resistant
FRONT PANEL MOUNTING
Front Panel Sealed to IP66
28mm diameter
S.P.C.O. Microswitch
5A, 250Vac
MPB038
Sealed to IP66
FRONT PANEL MOUNTING
Front Panel Sealed to IP66
21mm diameter
S.P.C.O. Microswitch
5A, 250Vac
MPB031
Sealed to IP66
FRONT PANEL MOUNTING
Front Panel Sealed to IP68
21.5mm diameter
S.P. Push to Make
1A, 50Vac/dc
MPB037
Sealed to IP68
Specification
MPB038
MPB031
MPB037
Terminations:
Solder Tags
Solder Tags
Screw Terminals
Switching:
S.P.C.O. Momentary Action
S.P.C.O. Momentary Action
S.P. Push to make
(Microswitch)
(Microswitch)
Momentary action
Max. Rating:
5A, 250Vac.
5A, 250Vac
1A, 50Vac/dc
Contact Resistance:
Insulation Resistance:
2A, 28Vdc
<10m ?
>10 3 M ? .
2A, 28Vdc
<10m ?
>10 3 M ?
<10m ?
>10 5 M ?
Dielectric Strength:
>2.0kVac
>2.0kVac
>1.0kVac
Operating Temp. Range:
–20?C to +70?C
–20?C to +70?C
–20?C to +70?C
Sealing (Front of panel only) : Protection Classification: IP66 EN60529
Protection Classification: IP66 EN60529 Protection Classification: IP68 EN60529
Operations
1992 (Micro switch not sealed)
1992 (Micro switch not sealed) 1992 (Terminals not sealed)
Mechanical:
1,000,000 (min)
1,000,000 (min)
1,000,000 (min)
Electrical:
35,000 (min)
35,000 (min)
30,000 (min)
Operating Pressure:
12.5N (typ)
4.7N (typ)
7.5N (typ)
Rear Nut Fixing Torque:
1.13Nm
0.57Nm
0.57Nm
Materials
Mouldings:
Glass Filled Nylon
Glass Filled Nylon
Glass Filled Nylon
Tags/Terminations:
Brass, Tin Plated
Brass, Tin Plated
Brass, Silver Plated
Switch Body & Button:
Brass, Chrome Plated
Brass, Chrome Plated
Brass, Chrome Plated
Contacts:
Fine Silver
Fine Silver
Brass, Silver Plated, Silver
Thread size:
1.0" x 26TPI
0.747" x 26TPI
0.747" x 26TPI
RoHS
Compliant
Compliant
Compliant
182
www.elektron-bulgin.com
